360 PIR

Category:

Description

  • Up to 7.6 m (25 ft) mounting height
  • Fully adjustable optics for coverage integrity and customization
  • Hinged chassis and base plate for easy installation
  • High efficiency LED and light pipe system for easy walk testing
  • First Step processing, or FSP
  • 360° x 21 m (70 ft) diameter pattern

Properties: Modular chassis and hinged mounting base design provide easy access to field setup switches and wiring.
Dimensions: 8.9 cm x 17.8 cm (3.5 in. x 7 in.)
Operating Temperature: -40°C to +49°C (-40°F to +120°F) For UL Certificated installations, 0°C to +49°C (+32°F to +120°F)
Sensitivity: Low/High gain settings
Complies with Environmental Class II (EN50130-5)
Height Range: 3 m to 7.6 m (8 ft to 25 ft) recommended
Location: Mounts directly to ceiling or to standard 10.2 cm (4 in.) octagonal electrical box.
Internal Pointability: Coverage is adjustable ±10° horizontally, +2° to -18° vertically.
Alarm Relay: Silent-operating form C relay. Contacts rated 125 mA, 28 VDC, 3 W maximum for DC resistive loads.
Tamper: Normally-closed (with cover in place) tamper switch. A wall (base) tamper is included. Contacts rated at 28 VDC, 125 mA, 3 W maximum.
Current: 12 mA standby; 39 mA in alarm with LEDs enabled
Voltage: 9 VDC to 15 VDC
